The unique modular design makes repair a breeze for any biomed or central supply department. The unit is made up of six (6) easy-to-replace modular components. Unlike the normal plastic inlet and outlet connections on most units, the cast metal backplate connections are extremely durable, thereby saving unnecessary repair costs. As a result of its modular design, the unit is 25-50 percent smaller than other suction regulators making it the product of choice for crowded wall and rail areas. The case is made of strong ABS plastic. It features a smooth surface with rounded corners making cleaning easy. The case also houses the gauge for extra protection. The large control knob with its three (3) easy-to-read settings make vacuum adjustments simple, even in emergency situations.

Specifications:

Bottom Connection (inlet) - DISS Male
Gauge Range:
PM3000: 0-200mmHg - Ful Vacuum
PM3000HV: 0-300mmHg - Full Vacuum
PM3100: 0-200mmHg - Full Vacuum
PM3100HV: 0-300mmHg - Full Vacuum
PM3500: 0-150mmHG
Gauge Accuracy:
Analog: ± 5% of Max
Digital Gauge: ± 1% of Full Scale
Analog Gauge: ± 5% of MAX within ref. indicator
Modes:
PM3100: LINE, OFF, REG
PM3000 and PM3500: OFF, REG
Maximum Vacuum:
PM3000 & PM3100: REG. Mode @ Full Vac - 396 mmHg (53 kPa)
PM3500D: Restricted to 170 mmHg (23 kPa) ± 10 mmHg (1.3 kPa)
PM3500E: Restricted to 160 mmHg (21 kPa) ± 10 mmHg (1.3 kPa)
Weight: 1.1 lbs. (.48 kg)
Dimensions: 3.7 in. (9.4 cm), 2.8 in. (7.1 cm), 5.2 in. (13.2 cm)
Battery: 3 Volt Lithium, ½ AA (Digital Vacuum Gauge Models ONLY)
